System Integrating

Involves developing technologies and tools that allow solar energy onto the electricity grid, while maintaining grid reliability security and efficiency.

THE ELECTRICAL GRID

For most of the past 100 years, electrical grids involved large-scale, centralized energy generation located far from consumers. Modern electrical grids are much more complex. In addition to large utility-scale plants, modern grids also involve variable energy sources like solar and wind, energy storage systems, power electronic devices like inverters, and small-scale energy generation systems like rooftop installations and microgrids. These smaller-scale and dispersed energy sources are generally known as distributed energy resources (DER).

The electrical grid is separated into transmission and distribution systems. The transmission grid is the network of high-voltage power lines that carry electricity from centralized generation sources like large power plants. These high voltages allow power to be transported long distances without excessive loss. The distribution grid refers to low-voltage lines that eventually reach homes and businesses. Substations and transformers convert power between high and low voltage. Traditionally, electricity only needed to flow one way through these systems: from the central generation source to the consumer. However, systems like rooftop solar now require the grid to handle two-way electricity flow, as these systems can inject the excess power that they generate back into the grid. See an infographic that explains how the grid works.

POWER ELECTRONICS

Increased solar and DER on the electrical grid means integrating more power electronic devices, which convert energy from one form to another. This could include converting between high and low voltage, regulating the amount of power flow, or converting between direct current (DC) and alternating current (AC) electricity, depending on where the electricity is going and how it will be used. By 2030, as much as 80% of electricity could flow through power electronic devices. One type of power electronic device that is particularly important for solar energy integration is the inverter. Inverters convert DC electricity, which is what a solar panel generates, to AC electricity, which the electrical grid uses.

GRID RESILIENCE AND RELIABILITY

The electrical grid must be able to reliably provide power, so it’s important for utilities and other power system operators to have real-time information about how much electricity solar systems are producing. Increasing amounts of solar and DER on the grid lead to both opportunities and challenges for grid reliability. Complex modern grids with a mix of traditional generation and DER can make responding to abnormal situations like storms or blackouts more difficult. However, power electronics have the potential to collect real-time information on the grid and help to control grid operations. In fact, special “grid-forming” inverters could use solar energy to restart the grid in the event of a blackout.
